Ricoh TH6310F Printhead, (1 color, 5PL) - J388-00
Ricoh TH6310F Printhead, (1 color, 5PL) - J388-00
| RICOH TH6310 | |
| Method | Thin-film piezoelectric transducer with bend mode |
| Print Width | 66.7mm |
| Number of nozzles | 1,600 (8 × 100 channels × 2 Modules), staggered(Net: 1,576) |
| Nozzle Resolution | 600npi |
| Nozzle spacing (Row to row distance) |
A: 0.677mm (8 pixels of 600npi) B: 20.909mm (494 pixels of 600npi) |
| Compatible ink | Aqueous, UV, Solvent, Others. |
| Total Printhead dimensions | W : 104.6mm D : 44.9mm H : 104mm |
| Weight | 374g |
| Max.number of color inks | 1 color |
| Operating temperature range | 140℉ (60℃) |
| Temperature control | Integrated thermistor, heater |
| Firing frequency | 80kHz(2 levels) 60kHz(3 levels) 40kHz(4 levels) |
| Grayscale | 4 levels |
| Drop volume | 5pL(Single drop) 5 ～ 18pL(Multi drop) |
| Viscosity range | 5.5mPa・s |
| Surface tension | 31.6±5mN/m |
| Ink circulation structure | 〇 |
| Separately sold parts | TH6310F dedicated cable |
